A Lightweight and User-Friendly EoH Framework for LLM-driven Automated Algorithm/Heuristic Design

• 2026.02 🎉🎉 New Champion! EoH won the CVRPLib BKS competition and established 51 new Best Known Solutions on large-scale CVRP benchmarks.
• 2026.01 🎉🎉 Our Survey Paper "A Systematic Survey on Large Language Models for Algorithm Design" has been accepted by ACM Computing Surveys ! A Rep for the Survey can be found here
• 2025.06 🎉🎉 We're excited to share that EoH recently set a New World Record in Circle Packing Problem, achieving a score of 2.63594 for 26 circles ! Results here
• 2024.05, EoH (Evolution of Heuristics: Towards Efficient Automatic Algorithm Design using Large Language Model) has been accepted at ICML 2024 (Oral, Top 1.5%)! 🎉

Heuristics are indispensable for tackling complex search and optimization problems. However, manual heuristic design is tedious and demands significant human intuition and experience.

EOH introduces a novel paradigm that leverages the synergy between Large Language Models (LLMs) and Evolutionary Computation (EC) for Automatic Heuristic Design (AHD). The coevolution of thoughts and codes within an evolutionary framework offers superior AHD performance while mitigating computational expenses.

EOH designs very competitive algorithms/heuristics in minutes/hours. Notably, it surpasses FunSearch, identifying superior heuristics with significantly fewer computational budgets (i.e., queries to LLMs) on online bin packing problem.

The following figure shows the evolution of EOH on the online bin packing problem. We outline the key thoughts and the corresponding code snippets that have contributed to the best results during evolution. Additionally, we mark the prompt strategies that result in improvement. Finally, we present the optimal heuristic in the final population and compare it to the heuristics designed by humans and from FunSearch.

If you find EoH helpful for your research or applied projects:

@inproceedings{fei2024eoh,
    title={Evolution of Heuristics: Towards Efficient Automatic Algorithm Design Using Large Language Model},
    author={Fei Liu, Xialiang Tong, Mingxuan Yuan, Xi Lin, Fu Luo, Zhenkun Wang, Zhichao Lu, Qingfu Zhang},
    booktitle={International Conference on Machine Learning (ICML)},
    year={2024},
    url={https://arxiv.org/abs/2401.02051}
}

If you are interested in LLM4Opt or EoH, you can:

1. Contact us through email fliu36-c@my.cityu.edu.hk.

2. Visit a collection of references and research papers on LLM4Opt

3. Join our QQ Group



If you encounter any difficulty using the code, you can contact us through the above or submit an issue

• python >= 3.10
• numpy
• joblib

We suggest installing and running EoH in a conda environment with python >= 3.10.

cd eoh
pip install .

Set up your endpoint and key for a remote LLM, or configure a local LLM, before starting!

from eoh import EoH, LLMConfig
from prob import MyProblem  # your problem class (see "Use EoH in Your Application" below)

llm = LLMConfig(
    api_endpoint="api.deepseek.com",  # e.g. "api.openai.com" or "api.deepseek.com"
    api_key="your-api-key",
    model="deepseek-chat",            # e.g. "gpt-4o", "deepseek-chat"
    timeout=150,
)

task = MyProblem(timeout=40, n_processes=4)

eoh = EoH(
    llm=llm,
    problem=task,
    pop_size=5,       # population size per generation
    n_pop=20,         # number of generations
    operators=['e1', 'e2', 'm1', 'm2'],
    output_dir="./results",
)
eoh.run()

cd examples/tsp_construct
python runEoH.py

Evaluation

cd examples/tsp_construct/evaluation
# copy your heuristic to heuristic.py (function name/input/output must match the evaluation block)
python runEval.py

(Generate a new best heuristic in 30 minutes on your personal computer! i7-10700 2.9GHz, 32 GB)

cd examples/bp_online
python runEoH.py

Evaluation

cd examples/bp_online/evaluation
# copy your heuristic to heuristic.py (function name/input/output must match the evaluation block)
python runEval.py

Define your problem by subclassing BaseProblem. You need to provide:

• template_program: a Python function (or class) skeleton the LLM will evolve.
• task_description: a one-sentence description of what the LLM should optimise.
• evaluate_program: a method that receives the generated callable and returns a float fitness (lower is better), or None on failure.

import numpy as np
from eoh import EoH, LLMConfig, BaseProblem


class MyProblem(BaseProblem):
    template_program = '''
def heuristic(x: np.ndarray) -> float:
    """Compute a score for input x."""
    return float(x.mean())
'''
    task_description = "Design a heuristic function that minimises the mean of the input."

    def evaluate_program(self, program_str: str, callable_func) -> float | None:
        # Replace with your actual evaluation logic
        score = callable_func(np.random.rand(10))
        return score  # lower is better


llm = LLMConfig(
    api_endpoint="api.deepseek.com",
    api_key="your-api-key",
    model="deepseek-chat",
)

task = MyProblem(timeout=30, n_processes=4)

eoh = EoH(llm=llm, problem=task, pop_size=5, n_pop=20, output_dir="./results")
eoh.run()

EoH supports three template kinds, detected automatically:

• function — a single function (most common).
• multi_function — multiple cooperating functions; the last one is the entry point.
• class — a class with a designated method; the class name is the entry point.

See examples/tsp_construct_class and examples/tsp_construct_multifunction for class and multi-function examples.

EoH supports three levels of heuristic design, offering increasing expressiveness. All three are illustrated using the TSP constructive heuristic task.

The simplest and most common form. The LLM evolves a single standalone function. The entry point is the function itself.

template_program = '''
def select_next_node(current_node: int, destination_node: int,
                     unvisited_nodes: np.ndarray,
                     distance_matrix: np.ndarray) -> int:
    """Select the next node to visit in a TSP greedy construction."""
    return unvisited_nodes[np.argmin(distance_matrix[current_node][unvisited_nodes])]
'''

The LLM evolves multiple cooperating functions. The last top-level function is the entry point; helper functions defined above it are called internally. This allows the LLM to decompose the heuristic into reusable sub-components.

template_program = '''
def compute_node_scores(current_node: int, unvisited_nodes: np.ndarray,
                        distance_matrix: np.ndarray,
                        destination_node: int) -> np.ndarray:
    """Compute a priority score for each candidate unvisited node."""
    return -distance_matrix[current_node][unvisited_nodes]


def select_next_node(current_node: int, destination_node: int,
                     unvisited_nodes: np.ndarray,
                     distance_matrix: np.ndarray) -> int:
    """Select the next node using compute_node_scores."""
    scores = compute_node_scores(current_node, unvisited_nodes,
                                 distance_matrix, destination_node)
    return unvisited_nodes[np.argmax(scores)]
'''

The LLM evolves an entire class. The class name is the entry point — EoH instantiates it and calls the designated method. This is the most expressive level, enabling stateful heuristics, internal data structures, and object-oriented design.

template_program = '''
class TSPConstructor:
    """Constructive heuristic for the Travelling Salesman Problem."""

    def select_next_node(self, current_node: int, destination_node: int,
                         unvisited_nodes: np.ndarray,
                         distance_matrix: np.ndarray) -> int:
        """Select the next node to visit."""
        return unvisited_nodes[np.argmin(distance_matrix[current_node][unvisited_nodes])]
'''

The table below lists all 33 example tasks included in the examples/ directory.

TSP Constructive Heuristic	BBOB Metaheuristic	Atari Breakout
tsp_construct	bbob_metaheuristic	ale_breakout

Set api_endpoint, api_key, and model in LLMConfig. Any OpenAI-compatible endpoint works:

llm = LLMConfig(
    api_endpoint="api.openai.com",   # or "api.deepseek.com", etc.
    api_key="your-api-key",
    model="gpt-4o",
    timeout=150,
)

Supported providers include:

• OpenAI API
• DeepSeek API
• Any other OpenAI-compatible endpoint

Set use_local=True and point local_url to your running inference server:

llm = LLMConfig(
    use_local=True,
    local_url="http://127.0.0.1:11012/completions",
    timeout=180,
)

The local server must accept POST requests in the format expected by api_local_llm.py. Any server that serves a Hugging Face model (e.g., via a simple Flask/FastAPI wrapper) and returns {"content": ["<generated text>"]} will work.

Subclass the LLM interface in eoh/src/eoh/llm/ to integrate any other LLM provider.

For answers to common questions about installation, LLM configuration, defining problems, evolutionary operators, results, and troubleshooting, see the FAQ.

Welcome to visit a collection of references and research papers on LLM4Opt

Fei Liu Rui Zhang Zhiyuan Yang Ping Guo
Shunyu Yao
