NiiMBOT macOS Printer Driver (AirPrint/IPP, Bluetooth)

Use your NiiMBOT label printer (D110_M, D110, D11, etc.) as a normal printer on macOS (Sonoma / Sequoia / Tahoe).
This project exposes a local AirPrint / IPP Everywhere queue so every app’s Print dialog works.
Jobs are rasterised and sent over Bluetooth (BLE) using @mmote/niimblue-node, with label size & density presets.

Tested device: NiiMBOT D110_M only (by the maintainer).
It should work with any printer models supported by niimblue-node.
Model-specific tweaks may be needed. Contributions and test reports are welcome!

• Works with macOS Sonoma 14 / Sequoia 15 / Tahoe 26
• AirPrint / IPP Everywhere queue (no vendor driver)
• Bluetooth (BLE) bridge via niimblue-node
• Real Paper/Label sizes in the Print dialog (presets supported)
• Multi-page documents: every PDF page becomes one label, printed as a single job
• Copies from the Print dialog (collated or uncollated), times an optional per-job quantity
• Density / darkness and print speed mapped from the Print dialog's Quality setting, within the model's supported density range
• Label type taken from the roll's RFID tag or the printer (configurable override)
• Printer status in the macOS queue: cover open, out of labels, battery low, feed error, wrong label type
• Supply levels in the printer name: after every job the macOS printer name reads e.g. Niimbot D110_M [Labels 81% · Battery 75%] (macOS's own Supply Levels panel ignores CUPS supply data for local IPP queues)
• Debug mode (keeps logs and rendered rasters in .spool)

• macOS 14+ (Sonoma)
• Node.js 20.9+ (brew install node); older versions fail at startup inside sharp
• Xcode Command Line Tools (xcode-select --install)
• ImageMagick (brew install imagemagick)
• Ghostscript (brew install ghostscript)
• ippeveprinter (ships with macOS as part of CUPS: /usr/bin/ippeveprinter)
• Bluetooth permission for your node/terminal app
  (System Settings → Privacy & Security → Bluetooth)

Put your printer’s BLE name into config/bridge.config.json:

{
  "NIIMBLUE_NAME": "D110_M-XXXXYYYY", // required
  "RENDER": "text",           // "text" or "photo"
  "THRESHOLD": "60%",         // used for RENDER="text"
  "DIRECTION": "",            // "", or "top"|"left"
  "ROTATE_FOR_LEFT": "0",     // "1" to rotate +90° when direction=left
  "LABEL_TYPE": "",           // "" = from the roll's RFID tag / printer; 1 gaps, 2 black mark, 3 continuous, 5 transparent
  "QUANTITY": 1,              // labels per copy (multiplied with Copies from the Print dialog)
  "SPEED": "",                // "" = from Quality (High -> 0); 0 = slower/higher quality, 1 = normal. D110M_V4-class printers only
  "COLOR": "",                // multicolor paper temperature (B1 / D110M_V4 only); "" = library default
  "PAGE_TIMEOUT_MS": 10000,   // timeout for sending one page's image data
  "STATUS_TIMEOUT_MS": 8000,  // timeout per status poll while waiting for the printer
  "STATUS_POLL_MS": 500,      // status poll interval
  "STATUS_IN_NAME": "1",      // append "[Labels 81% · Battery 75%]" to the macOS printer name after each job
  "DISPLAY_NAME": "",         // macOS printer name set by add-macos-printer.sh; "" = "Niimbot <model>"
  "DEBUG": "0"                // "1" = keep logs & .spool PNGs, "0" = quiet
}

You can override any setting at runtime with env vars: e.g. NIIMBOT_RENDER=photo ./scripts/start-printer.sh

# 0) Check the requirements above are met (all must print a path)
which node convert gs ippeveprinter

# 1) Clone & install
git clone https://github.com/olefrerichs/niimbot-macos-printer-driver.git
cd niimbot-macos-printer-driver
npm install

# 2) Discover your printer's BLE name
npm run scan:ble
# Example: D110-AB12CD34 or D110-ABCDEF1234

# 3) Put the name into config/bridge.config.json

# 4) Start the printer
chmod +x scripts/*.sh src/bridge.mjs
./scripts/start-printer.sh

# 5) Add the printer in macOS
./scripts/add-macos-printer.sh
# (adding ipp://localhost:8631/ipp/print manually in System Settings also works,
#  but then set Quality=High and the printer name yourself)

• Paper Size → pick your label (e.g. 12×40 mm)
• Quality → Draft = lowest density, Normal = the model's default, High = highest density and, on D110M_V4-class printers, the slower high-quality print mode
• Copies → prints that many labels per page; multi-page documents are collated unless the dialog says otherwise
• Pages → each page of the document is one label; use Pages: from/to to print a subset
• Save Presets: Presets ▸ Save Current Settings as Preset… (e.g., “12×40 High Density”)

Two rasterisation modes:

• Text (default): sharp edges, thresholded, good for codes/logos
• Photo: Floyd–Steinberg dithering, better for gradients/photos

Switch at launch:

NIIMBOT_RENDER=text   ./scripts/start-printer.sh   # crisp logos/text
NIIMBOT_RENDER=photo  ./scripts/start-printer.sh   # dithering for photos
NIIMBOT_THRESHOLD=62% ./scripts/start-printer.sh   # fine-tune threshold

Enable Debug to keep logs and rendered job images: NIIMBOT_DEBUG=1 ./scripts/start-printer.sh

# Logs:   .spool/ippeve.log
# Images: .spool/job-*.png

When Debug=0 (default), .spool is emptied on start and logs are suppressed.

cd niimbot-macos-printer-driver
git pull
npm install                      # picks up dependency changes
which gs || brew install ghostscript   # required since v0.2.0
launchctl kickstart -k gui/$(id -u)/local.niimbot.ipp   # restart if you use the LaunchAgent
./scripts/add-macos-printer.sh   # re-create the macOS queue when the release notes say the PPD changed

If you started the printer manually instead, stop it and run ./scripts/start-printer.sh again.
Re-creating the queue regenerates the macOS-side PPD (paper size names, quality default); your saved presets in the Print dialog keep working.
git pull keeps your edits to config/bridge.config.json unless the release changed that file too; if it complains, run git stash && git pull && git stash pop.

Install the LaunchAgent:

./scripts/install-launch-agent.sh
launchctl kickstart -k gui/$(id -u)/local.niimbot.ipp

• The LaunchAgent runs scripts/start-printer.sh at login.
• Printer name & defaults are read from config/bridge.config.json.
• To enable persistent debug mode, set NIIMBOT_DEBUG to 1 in the installed plist and reload it (kickstart alone keeps the old environment):

P=~/Library/LaunchAgents/local.niimbot.ipp.plist
plutil -replace EnvironmentVariables.NIIMBOT_DEBUG -string 1 "$P"
launchctl bootout gui/$(id -u)/local.niimbot.ipp; launchctl bootstrap gui/$(id -u) "$P"

Set it back to 0 the same way; .spool is emptied on the next start.

• Queue says “In Use” then “Idle” but nothing prints
  Enable debug (NIIMBOT_DEBUG=1), print a simple PDF, check .spool/ippeve.log.
  Open .spool/job-*.png — this is exactly what gets sent to the printer.

• Print direction rotated
  Set "DIRECTION": "top" in config/bridge.config.json (or NIIMBOT_DIRECTION=top).

• Too light/dark
  Adjust Print dialog Quality or tweak "THRESHOLD" in config.

• Queue shows “Cover open”, “Out of labels”, “Low supply”, ...
  The printer reported the condition before or during the job. Fix it and print again; the status clears with the next job.

• Supply levels
  Remaining labels (from the roll's RFID tag) and battery charge are appended to the printer name after every job (disable with "STATUS_IN_NAME": "0") and reported to CUPS:
  ipptool -tv ipp://localhost:631/printers/Niimbot_BLE get-printer-attributes.test | grep marker-.
  macOS's Options & Supplies → Supply Levels panel shows “Information Not Available” for this queue; it only fetches supplies from Bonjour-discovered printers, not from CUPS.

• PDFs don’t print (queue shows the job for a second, then it disappears; ippeve.log says convert failed)
  Ensure both ImageMagick and Ghostscript are installed (brew install imagemagick ghostscript).
  Test with convert -density 406 some.pdf out.png — gs: command not found means Ghostscript is missing.

• Models: Any with a print task in niimbluelib (D11, D110, D110_M, D101, B1, B21 variants, B21_PRO, B1_PRO, H1S, and more; about 80 models are recognised).
  Confirmed by the maintainer: D110_M (protocol v4).
  npm run info connects to your printer and prints its model, firmware, battery and the detected print task.

• Roll sizes (preconfigured):
  12×22, 12×30, 12×40, 12×75, 12×109 mm
  14×30, 14×40, 15×30, 15×50 mm

  (See config/niimbot.ppd for details.)

• Optional pure-Node IPP server (no ippeveprinter dependency)
• Homebrew formula for one-command install
