Validation of SVG #1323
Description
See w3c/epubcheck#1172. The WG should probably talk about how to deal with a world with SVG 1.1 and SVG2
See w3c/epubcheck#1172. The WG should probably talk about how to deal with a world with SVG 1.1 and SVG2
Activity
Doktorchen commentedon Aug 5, 2020
Currently SVG2 is not a recommendation and there is no SVG2 specific version indication, but of course authors can use metada for example with dublin core to indicate which version they have used.
EPUB 3.2 does not indicate, which version to use, therefore it is up to the authors, what to use:
1.0, 1.1 first edition, 1.1 second edition (tiny, basic of full), tiny 1.2.
All of them have a version indication, validation or presentation programs have to respect this.
But if there is no version indication at all, it is up to the program, how to interpret the content.
For a check program there can be different approaches helpful for authors in case of a missing version indication:
Most important: Inform, what version was used for the validation, else the result is useless (applies for HTML5.x as well).
Alternative approaches to chose a version to check:
a) Guess according to the content starting from 2.0 down to 1.0
b) Assume the newest recommendation (relative to the release date of the program)
c) Guess from the date, the document was produced, if available.
d) Indicate missing version information and provide a report for at least 1.1.2; tiny 1.2 and maybe 2.0 (if it becomes a recommendation at all; once alread 1.2 full did not go beyond a draft, only tiny 1.2 with lots of other features became a recommendation).
iherman commentedon Aug 11, 2020
Just for the record: w3c/epubcheck#1114 if is also relevant if it comes to discussion in the (C|W)G on real world SVG, although it touches upon a more general issue regarding the usage (or not) of external references
murata2makoto commentedon Oct 2, 2020
Let me ask a naive question. Does epubcheck rely on SVG schemas prepared by us? Or, does it now rely on validator.nu?
mattgarrish commentedon Oct 2, 2020
Mostly this.
We're trying not to fundamentally differ from the results that web validation produce, but we do extend the schemas for epub-specific rules.
bduga commentedon Oct 2, 2020
I question whether we should be bothering to check for validity of SVG documents. Per Doktorchen's comment it is not trivial, and it is hard to determine if you have even done it correctly. What do we gain from it? It seems like it only tells us that there exists or existed at some point a schema that validated a document. Unlike HTML, SVG doesn't really add much semantic meaning for reading systems from the structure of the file, what is most important is the ability to render the document and the inclusion of any a11y features, neither of which are guaranteed by validity. Additionally, SVGs are rarely edited by hand, so content creators are at the mercy of graphics tools to generate documents that are valid to some schema someone somewhere might use to check the document.
If we do plan to keep validity, we should make it very clear which schema(s) SVG must be valid to.
mattgarrish commentedon Oct 2, 2020
How do we square this with the restrictions in the specification?
Are we just loosening epubcheck and in theory having restrictions, keeping the epub-specific stuff and dropping validity checks against any specific version of svg, or removing all the content requirements (even that the document be well-formed xml)?
bduga commentedon Oct 2, 2020
Excellent question! And looking at the spec ... which restrictions? Looks like we lost validity for both XHTML and SVG somewhere between 3.0 and 3.2. Specifically, in 3.0 we said:
But in 3.2 we say:
Similar is true for XHTML. So is this simply an error in epubcheck? Should we not be checking for validity anymore?
mattgarrish commentedon Oct 2, 2020
It just looks like that reference is dead. We didn't move to drop validity unless you remember a resolution to that effect? There just isn't a schema defined in SVG and we can't point at epubcheck.
I expect it should (if we keep validation) be updated to cite the "Conforming XML-compatible SVG Markup Fragments" conformance class, which would let us drop the XML conformance bullet.
But, regardless, we still have some content requirements that aren't related to general validity. The identifying of XHTML fragments, for example, the restriction on title, etc. Do we check these if we don't check against a default schema?
We probably should make a normative statement for XHTML, too. It looks like we've always relied on this in the relationship section to blanket cover validity to the specification:
murata2makoto commentedon Oct 2, 2020
@bduga
EPUB is intended to be in sync with the reality of the Web. Meanwhile, the longevity of EPUB publications is crucial.
I think that relying on validator.nu (including the choice of schemas for SVG) is probably the best approach. Dropping validity checking from epubcheck may well endanger the longevity of EPUB publications.
mattgarrish commentedon Oct 2, 2020
Hunting around a bit, we dropped the validity statement in 3.1 but I can't find any specific mention of it in the minutes or issues.
But it still looks like an omission to have not updated the reference, as the one in embedded SVG was updated to the fragment class in 3.2.
For standalone, I put the wrong class above, though. It should be Conforming SVG Stand Alone-Files
bduga commentedon Oct 2, 2020
I am not sure how this works with the spec. Specifically, this is not a discussion about epubcheck, though I expect it will have implications there, it is an EPUB question. Given my reading of the spec, there is currently no validity requirement for SVG. We may want to put that requirement back, but I am not sure how to do that and maintain references to living documents. Do you have a proposal for how to draft such a requirement?
I do think that if we can't add a requirement to the spec we shouldn't require validity in epubcheck, although we could allow for optional checks by passing a version to epubcheck (or some other mechanism).
bduga commentedon Oct 2, 2020
And, for what it is worth, I like Matt's proposal.
iherman commentedon Oct 3, 2020
I believe Matt's proposal would still keep w3c/epubcheck#1114 open. To quote that issue: SVG 1.1, per spec, relies on:
Because the
svg11.dtduses XML DTD modularization, it is full of entities. However, as Matt commented, those are forbidden by EPUB. As a consequence, EPUBCheck systematically refuses such SVG files, although they are perfectly valid per SVG Spec.The problem with this illustrates Brady's comment:
As a typical example, Adobe Illustrator systematically puts that DOCTYPE into a generated SVG files (or it did until the latest release, I did not check the last one).
This goes beyond SVG, mind you. MathML has the same problem afaik. I believe we may have to come back to the problem of how to handle XML entities.
B.t.w., the possible solution that came up w3c/epubcheck#1114 is to explicitly put exceptions to the entity rules concerning some standard DTD-s (that XML parsers are not really required to fetch anyway).
7 remaining items
iherman commentedon May 14, 2021
The issue was discussed in a meeting on 2021-05-13
View the transcript
6. SVG Validation
See github issue #1323.
Dave Cramer: one of the complicating factors is undated references to specs, and now we have SVG1 and SVG2
Brady Duga: would prefer if we didn't validate SVG
… this came up because there was an SVG 1.1 with a
rel=no refer, and this failed epubcheck… i've found a couple other SVG validation errors that came up because of things that weren't valid in 1.1
… and even if we do validate, we can only say that it was valid to an SVG Schema at the time of validation
Matt Garrish: compounding the problem is that
validator.nuhas partially gone with SVG2, with no plans to fully move to SVG2Brady Duga: i understand need for validity of XHTML, as XHTML is often edited by hand
… not true for SVG, which are often made by tools
… so you're putting authors at the mercy of their tools, if those tools are generating invalid SVG
… and note that at this point spec doesn't require validation
Dave Cramer: is there a requirement for well-formedness of XML?
Ben Schroeter: what about the XML entities in the DTDs of the SVG?
Dave Cramer: we're not touching anything about rendering or processing, just saying that spec does not require validity, therefore epubcheck does not need to check validity
Brady Duga: if we don't have requirement for validity, then Ivan's issue goes away
Matt Garrish: i we've always had requirement that things conform to XHTML syntax
… but what about when SVGs are embedded in the content?
Dave Cramer: maybe our current action item is to talk to Romain about how this would affect epubcheck
… would also like to hear what Ivan says about this
iherman commentedon May 14, 2021
I presume that referred to w3c/epubcheck#1114. But that issue is already gone in the current version of the spec which explicitly lists SVG (and MatML) DTD-s as acceptable.
iherman commentedon May 14, 2021
To help the discussion, here is the summary of what SVG says about conformance.
The SVG2 spec defines SVG Conformance classes:
idattribute is valid forxml:id). Ie, it is also in line with CSS.svgroot element, and, otherwise, is along the lines of (3).It is all a bit convoluted, because (I presume) the SVG2 spec is prepared for SVG content embedded in HTML, including the looser syntax of HTML vs. XHTML.
I guess for our content documents the reference to (5) is the correct one, and that is (almost) what we have in the spec. Almost, because (I think @mattgarrish mentioned that some somewhere) in §3.2.2 SVG Requirement the (correct) links refers to "SVG document Fragment"; it should rather say "Conforming SVG Stand-Alone Files".
iherman commentedon May 14, 2021
I believe that, ideally, we should (1) keep what we have and (2) let us rely on
navigator.nufor validation, unless the SVG check ofnavigator.nuis so bad that it does more harm than good...CC @rdeltour
bduga commentedon May 14, 2021
I think what we have now (unless @mattgarrish has changed it) is no validity requirement, but that was likely an accidental change.
That is precisely the issue. The validation is causing real harm today, forcing ignore list updates to process SVGs. There have been claims of potential harm caused by not requiring validity for SVG, but I have not seen any specific cases (real, identifiable cases of harm that were avoided by validation of SVG). The evidence currently is that validation is causing more harm than good, but I am happy to review evidence to counter that.
mattgarrish commentedon May 14, 2021
Nope, we're still lacking a validity requirement for svg as far as I can tell. All I fixed was the reference to the standalone definition, but that corresponds to 5. in Ivan's list above. The SVG has to be well-formed XML and the IDs have to be unique (which is also all accessibility requires) but the markup doesn't have to be valid.
We have to separately require conforming SVG DOM subtrees (1. in the list) as far as I can tell. None of the definitions appear to refer to it.
(By comparison, for XHTML we require both that a document "MUST be an [HTML] document that conforms to the XHTML syntax" and that it "conform to the conformance criteria for all document constructs defined by [HTML] unless explicitly overridden in § 3.1.4 HTML Deviations and Constraints".)
The problem with relying on what validator.nu implements is that its implementation is not complete, so what you're asking is that vendors tolerate invalid SVG content or that epubcheck has to fill in missing validity constraints as users stumble on them.
Is either of these options really better than laxer validation that only requires well-formedness and the few other requirements in the definitions?
There are also likely options for validating SVG in epubcheck without needing the specification to be strict about validity. I believe we're using nvdl to validate xhtml, so that should make it possible to validate embedded svg separately from the containing document, but this is where we need @rdeltour's input.
If that is the case, though, perhaps SVG validity problems could be output as info messages rather than as warnings or errors?
iherman commentedon May 15, 2021
@mattgarrish:
I was fighting with this yesterday, looking through the SVG spec and (re-reading it again) indeed it looks as if we would have to refer to the DOM conformance separately. Meaning I was wrong: we indeed do not have a validity requirement at this moment, beyond what, essentially, XML validity requires.
(I must admit I was a bit surprised by the way the SVG spec defines all this, the HTML conformance seems to be way clearer.)
@bduga:
@mattgarrish:
Taking also into account that SVG itself is still a bit of a moving target (in CR, without change, since 2 1/2 years...) maybe we can indeed say that we do not require SVG validation for now.
+1 to that (if it is possible).
I still wonder whether
iherman commentedon May 21, 2021
The issue was discussed in a meeting on 2021-05-21
List of resolutions:
View the transcript
1. Validation of SVG
See github issue #1323.
Dave Cramer: Validation of svg
… Perhaps coming to consensus
… maybe keep status quo
… don't require validity now, just well formed, etc
… duga mentions there is real harm to the validity check
… propose informative messages when
validition.nucheck fails… no spec change, acknowledge reality of tools
Ivan Herman: Fundamentally agree
… Which category corresponds to the epub check behavior?
Dave Cramer: Weird case since epubcheck is currently out of sync
… with the spec.
Matt Garrish: epubcheck follows the spec, but not entirely bound to it
… epubcheck can do what it wants, only errors and warnings need to match spec
… . Doesn't need a statement in the spec to justify it
